More Superhard Company specializes in the production of all kinds of high-end ceramic bonded and metal boned CBN/diamond grinding wheels, honing stones and other abrasive products.
We provide superabrasive diamond and CBN honing stone for honing machines of almost all renowned honing brands (Sunnen, Nagel, Belden, AccuCut, Engis, and other types of high-production honing equipment ). Our diamond and CBN honing stones are available for precisiom bore finishing.
Materials of workpiece: carbide,glass and ceramic,cast iron,alloy steel, tool steel, die steel, hardened steel copper, aluminum alloy and other abrasive resistant materials
Applicable area: fine grinding engine pump body, hydraulic cylinder bore, hydraulic pump inner bore, cylinder block, valve,oil cylinder nozzle, the inner surface of the spline bore and cylinder hole and blind hole of other series.
Applicable honing machine:Sunnen, Nagel, Belden, AccuCut, Engis, and other types of high-production honing equipment
| Model | Size | Grit | ||
| diamond and CBN honing stone | L (mm) | Width (mm) | Height (mm) | 120#～150# 150#～240# 240#~W40 W40~W20 ＜W20 |
| 16-35 | 2, 3, 4, 6 | 2, 3, 4 | ||
| 40, 50 | 2, 3, 3.5, 4 | 1, 1.5, 2, 2.5, 3, 3.5, 4 | ||
| 60, 70 | 1.5, 2, 3, 3.5, 6, 8 | 2, 2.5, 3, 3.5, 4, 6.5, 7, 8 | ||
| 80, 90 | 3, 4, 5, 6, 8, 9, 9.5 | 3, 4, 5, 6, 7, 8, 10 | ||
| 100, 120 | 2, 3, 5, 6, 8, 9, 12, 15 | 3, 4, 5, 6, 7, 8, 10, 12, 15 | ||
| 140, 150 | 3, 5, 6, 8, 9, 12 | 4, 5, 6, 7, 8, 10, 12 | ||
| 200 | 8, 10, 15, 20, 40 | 8, 10, 15, 20 | ||
| Other specifications honing stone can be made according to customers' requirement. Email: [email protected] | ||||
CBN honing stones (90* 8* 8) have sent to Latvian clients and got a good feedback
 | CBN honing stone size | 90* 8* 8 |
| workpiece | cast iron cylinder honing | |
| applicable honing machine | Rottler H85ax honing machine |
