CBN Grinding Wheel For Internal Grinding

CBN Grinding Wheel For Internal Grinding

Model: 1A8, 1A1W, 1A1

Bonded: Vitrified bond (ceramic bond)

Abrasive: CBN and Diamond

Shape: cylindrical

Suitable: inner surface

Application: internal grinding of of hydraulic tappets, universal joint, stator and rotor , etc

Alias: ID Grinding Wheel, Internal Grinding Wheel, Inner
Application: internal grinding auto parts
e-mail: sales@moresuperhard.com
Details

The Features of CBN grinding wheel for internal grinding

High workpiece precision. More porous existed in abrasive,easy to dress body and are good at large surface grinding. High porous rate shows a good chip performance, it is impossiple to burning workpiece. Good workpiece consistency, Long life time .

Applications of CBN grinding wheel for internal grinding

Grinding of Con-rods ends in the Auto Industry .

Grinding of Hydraulic and Pneumatic Cylinders .internal grinding

CVJ ball-cage, inner and outer raceway .

Hydraulic tappet of automobile motor .

Grinding of Bores of Inner Rings .

Grinding of Gears Bores, Collects.

Pump stator of automobile,Grinding of Gun Barrels .

Roller, cylinder, flange cover of air-condition compressor.

Grinding of Inner and outer faces of Ball & Roller Bearings .

Specification of CBN grinding wheel for internal grinding

Models & Profile Diagram

Details Size

1A8 cbn internal grinding

1A8 D * T * H (mm)

D

4mm - 45mm

H

1.5mm - 30mm

T

5mm - 50mm

DW cbn internal grinding wheel

1A1W D * T * H * L * M (mm)

D

7.5mm - 50mm

H

4mm - 45mm

T

15mm - 50mm

1A1 cbn internal grinding wheel

1A1 D * T * H * X (mm)

D

18mm - 50mm

H

10mm - 40mm

T

15mm - 50mm

The two types of vit CBN grinding wheel for inner grinding: ID Wheel with Shank, ID Wheel without Shank

Hydraulic Industry. 1A1W Vit CBN Internal Grinding Wheel

inner grinding wheel vitrified cbn grinding wheel for inner grinding

Cylinder Sleeve Grinding of Vitrified CBN Inner Wheel

vitrified cbn internal grinding wheel vitrified cbn grinding wheel for inner grinding

CVJ Ball Cage Grinding of Vit CBN Grinding Wheel for Inner Grinding

CVJ ball cage cbn internal grinding wheel cbn internal grinding wheel

Rotary Vane Compressor Stator Grinding of CBN Grinding Wheel for Inner Grinding

vitrified cbn internal grinding wheel vitrified cbn internal grinding wheel

We can also produce Vitrified Diamond Inner Wheel, Resin Diamond Internal Wheel and Metal Diamond Internal Wheel (1A1, 1A8, 1A1W, 1B1)

PCD Bearing Parts Grinding of Vitrified Diamond Internal Grinding Wheel

vitrified diamond grinding wheel vitrified diamond grinding wheel for inner grinding
